Thermopile Modules

Application Notes


Devices

Analog Output / Narrow Field Of View

package 6pin TO5/TO39 - lens optics - calibration for temperature
Datasheet HIS Lx FL5.5 Tx

package PCB with connector - lens optics - calibration for temperature
Datasheet HTIA Ex L4.4-F5.5 Tx

package PCB with connector - mirror optics - calibration for temperature
Datasheet HTIA Dx Tx

Analog Output / Wide Field Of View

package 6pin TO5/TO39 - calibration for temperature - cap aperture without optics
Datasheet HIS Ax1 Fx Tx 6PIN

package 6pin TO5/TO39 - fixed gain adjustment - cap aperture without optics
Datasheet HIS Ax1 Fx Gx 6PIN

package PCB with connector - calibration for temperature - cap aperture without optics
Datasheet HTIA Cx Tx

Digital Output / Narrow Field Of View

package 6pin TO5/TO39 - lens optics - temperature output via SM-Bus or PWM
Datasheet HID L1x FL5.5 Tx

Digital Output / Wide Field Of View

package 6pin TO5/TO39 - cap aperture without optics - temperature output via SM-Bus or PWM
Datasheet HID A1x Fx Tx

package 8lead SMD 5x5(mm) - 3V/5V by external wiring - temperature output via SM-Bus or PWM
Datasheet HCM G15 Fx Tx
