Integrated Sensors

Application Notes


Devices

Single-Channel with Analog Outputs

package 4pin TO5/TO39 - factory set gain 5600 - supply voltage 5V
Datasheet HIS Ax1 Fx G5600

package 4pin TO5/TO39 - selectable preset gain 2150 / 4300 - supply voltage 2.7V-5.5V
Datasheet HIS Ax2 Fx Gx

package 4pin TO18/TO46 - selectable preset gain 2150 / 4300 - supply voltage 2.7V-5.5V
Datasheet HIM Jx2 Fx Gx

package 8lead SMD 3.8x3.8(mm) - adjustable gain 2150 / 4300 - supply voltage 2.7V-5.5V
Datasheet HCM Cx2 Fx

Dual-Channel with Analog Outputs

package 4pin TO5/TO39 - selectable preset gain 2150 / 4300 - supply voltage 2.7V-5.5V
Datasheet HIS E222 F1 F2 Gx

Single-Channel with Digital Output

package 4pin TO5/TO39 - SM-Bus by default - optional PWM - supply voltage 3V or 5V
Datasheet HID A2x Fx Gx

Dual-Channel with Digital Output

package 4pin TO5/TO39 - SM-Bus by default - optional PWM - supply voltage 3V or 5V
Datasheet HID E22x F1 F2 Gx.pdf
